SeaCalm Gimbaled Cupholder
TECHNICAL SPECIFICATIONS
| CONSTRUCTION – INVESTMENT CAST | 316 STAINLESS STEEL | |
| BASE ROLLER BEARINGS | STAINLESS STEEL | |
| YOKE ROLLER BEARINGS | STAINLESS STEEL | |
| HEIGHT | 120mm | 4¾" |
| WIDTH | 108mm | 4¼" |
| DEPTH | 120mm | 4¾" |
| WEIGHT | 0.544Kg | 1¼Lb |
| BOXED WEIGHT | 1. 04Kg | 2¼Lb |
| BOX HEIGHT | 178mm | 7" |
| BOX WIDTH | 190mm | 7½" |
| BOX DEPTH | 135mm | 5¼ |
| SWING
RADIUS (at 45deg-side to side) Allowance from centreline each side |
100mm | 4" |
|
SWING
RADIUS (at 30deg-fore and aft) |
160mm | 6¼" |
| MOUNT (supplied) | Dovetail – stainless | |
| MOUNT BOLTS (supplied) | 3/1 6"W – nyloc nuts c/sunk | |
| MOUNT SCREWS (alternative, supplied) | No.5 self tapping c/sunk | |
| MAX. DIAMETER OF FLUID CONTAINER | 82mm. | 3¼" |
